Battery Equalizer

What is Battery Equalizer?

Battery Equalizer improves battery chemistry. This stops shedding and prevents sulfation from occurring in new batteries, and breaks up existing sulfation in older batteries. Battery Equalizer returns batteries as close to new as possible. With continued normal maintenance, Battery Equalizer :•

  • Increases Battery Life by reducing sulfation process.
  • Increases Charge Acceptance
  • Increases Discharge (Running) Time
  • Increases Storage Time

(Battery Equalizer will not fix or repair a dead cell.)

Why Control Sulfation?

                  Sulfation is a residue that remains on the batteries plates after current is produced. This residue increases with each charge and discharge cycle as the battery ages. Over time the residue/resistance will choke out a batteries ability to produce or store an electrical current. Sulfation is a natural part of a battery’s chemistry; historically, over charging or “equalizing charge”, has been the only way to reduce the build up of sulfation. Battery Equalizer is the only product in the market to effectively reduce existing sulfation and prevent new sulfation by improving the battery chemistry.

Why Develop Battery Equalizer?

                  The concept of cleaning out batteries has been going on for years. People would wash them out using a simple jet of water or quite commonly a mixture of Epsom salts and water. Of course there are a great many drawbacks to this process, i.e. It takes away many of the elements originally placed in the paste design by the battery manufacturers and the salts will attack the lead, dry it out so that it may become even more brittle and totally upset the specific gravity levels. Battery Equalizer is designed to clean and alloy the working parts within a lead acid battery by means of electrochemical reaction.

Enhances battery life and performance.

                  Our Battery Equalizer is a unique product that equalizes two or more batteries in a battery bank connected in series and corrects their imbalances. Battery equalizer enhances the battery life by preventing under charge and over charge of the batteries. When batteries in different states of charge are connected in series, there are chances that the weaker battery becomes weaker and the stronger battery gets overcharged. This leads to a reduction in the life cycle of the overall string of batteries, as against the original life expectancy. The battery equalizer prevents this adverse effect on the batteries and there by increases the working life of the entire string of batteries. Our Battery Equalizer which provides perfect voltage matching of the batteries during both charge and discharge, bringing longer life cycle , lower rates of failure and easy maintenance.

Principle of Battery Equalizer :

  • We are manufacturing Battery Equalizer with an active charge balancing system for improving the efficiency and extending the battery life of batteries connected in series.
  • Using an efficient switched capacitor model instead of dissipative balancing model, this system iscapable of maintaining a 40mV difference between batteries connected in series.

Advantages of Battery Equalizer :

  • When there are more than 2 batteries in the series, it will equalize the voltage in them and ensure they do not have different voltages.
  • Protects your batteries from undercharging and overcharging, which reduces their working life.
  • Extends battery life and capacity appreciably.
  • Reduces the frequency of battery replacement, thus reducing cost and saving money.
  • Easy to install with batteries connected in series.
  • Operates in all 3 modes: battery charging, discharging or in idle mode.
  • Compact size, Low weight. Low cost.

Features of Battery Equalizer :

  • Active equalization technique based on flash micro-controller.
  • Reduces the battery replacement, which again greatly reduces the cost.
  • Easy to install with batteries connected in series.
  • Suitable for ‘N’ numbers of batteries by utilizing multiple units together.
  • Operates in all three modes: battery charging, discharging or in idle mode.
  • Appropriate for Gel, Sealed and AGM Lead Acid batteries.
  • Works with conventional flooded lead acid batteries and SMF batteries.
  • Extends battery life and run time.
  • Prevents over and under charge due to battery imbalance.
  • Potential free battery fault alarm contact available for external alarm.
  • No external power required.
  • Can be use for various battery voltages 2 VDC to 12VDC.
  • Suitable for any AH capacity of Battery.

Applications of Battery Equalizer :

  • Battery Bank
  • Electric Vehicle
  • Solar Systems
  • Generators
